Brand
|
PELADN
|
|
Product Model
|
WO4 6600H
|
|
CPU
|
AMD 6600H / Cores: 6 / Threads: 12 TDP: 45W
|
|
Base Clock: 3.3GHz Max. Boost Clock: 4.5GHz
|
|
|
Graphics Card Model
|
AMD Radeon Graphics 660M / Graphics Card Frequency: 1900 MHz
|
|
Cache
|
16MB
|
|
SO DIMM DDR5
|
16G 4800MHz / Maximum Support 64GB
|
|
SSD PCIE 4.0
|
M.2 NVME SSD 2280 Maximum Support 4TB
|
|
SSD PCIE 3.0
|
M.2 NVME SSD 2280 Maximum Support 4TB
|
|
Wireless LAN / BT
|
9852BE / M.2 E_key WiFi 6.0 / BT 5.2
|
|
Interface
|
USB3.2
|
|
USB 2.0
|
|
|
2.5G Local Area Network(RJ45)
|
|
|
1G Local Area Network(RJ45)
|
|
|
Audio Jack(HP&MIC)
|
|
|
HD 2.0 4K 60Hz
|
|
|
DP 1.4 4K 60Hz
|
|
|
USB 4.0 Maximum Support 40GB Data Transmission
|
|
|
Type-C Support Video / Data Transfer
|
|
|
DC Jack 5.5*2.5
|
|
|
Power Button
|
1
|
|
Operating System
|
Windows 11 PRO
|
|
Power Adapter
|
AC 100~240V
|
|
Input: 100~240V AC, 50/60Hz, Output: 19V / 6.32A
|
|
|
Working Environment
|
-10℃~45℃, 30%-90% Humidity
|
|
Storage Environment
|
-20℃~60℃, 10%-90% Humidity
|
|
Fittings
|
Wall Mount Bracket, Screw Packs
|
|
HD 100CM
|
|
|
Adapter 19V / 6.3A
|
|
|
Additional Features
|
Power On Automaticially
|
|
Dimension
|
128*128*52mm
|
|
Weight
|
Only Device: 0.55KG
|
|
With Accessories: 1.55KG
|
